Vortex EF2280 – Multi-channel AEC / Noise canceller w/Auto Mic Mixing and Matrix Mixer (2200-12280-001) – Polycom Vortex

The Vortex® EF2280 is a multichannel acoustic echo and noise canceller with integral automatic microphone / matrix mixer. It is a complete all-in-one solution for audio and video conferencing, distance learning, courtrooms, and more.

Description

The Vortex® EF2280 is a multichannel acoustic echo and noise canceller with integral automatic microphone / matrix mixer. It is a complete all-in-one solution for audio and video conferencing, distance learning, courtrooms, and more.

  • 12 inputs, 12 outputs, 8 mic/line input channels
  • Acoustic Echo Cancellation and ambient noise cancellation on each mic/line input
  • 25 x 18 Matrix mixer with user-adjustable cross point gains
  • Voice-driven AGC utilizing neural network processing – activates only on valid voice signals
  • 5-band parametric EQ on each input channel and output channel
  • Selectable 24V phantom power available on each mic input
  • Full Bandwidth performance – 20 Hz to 20 kHz throughout
  • Connect up to 8 Vortex units, with control of NOM over all units
  • Over 10dB of room gain allowed by system
  • “Conference Composer” Software provides easy programming
  • 32 user-programmable presets, 16 factory programmed presets
  • Macros (mini-presets) allow further customization of presets
  • Fully configurable logic 24 logic inputs, 20 logic outputs
  • Two Automatic Microphone Mixers included to allow room combining
  • 40 dB/second AEC convergence
  • 270 ms echo cancellation span
  • User selectable noise cancellation – 6, 10 or 15 dB
  • Fully RS232 controllable
  • Infrared remote available
  • No. of mic inputs: 4
  • No. of line inputs: 4
  • No. of line outputs: 12
  • PSTN Interface: No
  • Auto mic mixer: Yes
  • Noise cancellation: Yes
  • Auto gain control: Yes
  • EQ on input/output: Yes
  • Echo cancellation: 8 Channels
  • VTX 1000 interface: Yes
  • 10W amplifier: No
  • RS232 interface: Yes
  • # of linked devices: 8 Max.
  • Quick install packs: No
  • Manufacturer Part Number: 2200-12280-001
