Vortex EF2241 – Multi-channel AEC / Noise Canceller w/ Auto Mic Mixing, Matrix Mixing and Telephony Interface (2200-12241-001) – Polycom Vortex

Call for Price

The Polycom Vortex EF2241 is typically installed in smaller rooms that require audio conferencing, or as a companion to the Polycom EF2280 Vortex. Based on the technology of our popular Vortex audio conferencer, the EF2241 offers 4 mic/line inputs, 4 line inputs, 8 line outputs, an integrated phone add, and a 10-watt power amplifier.

Description

The Polycom Vortex EF2241 is typically installed in smaller rooms that require audio conferencing, or as a companion to the Polycom EF2280 Vortex. Based on the technology of our popular Vortex audio conferencer, the EF2241 offers 4 mic/line inputs, 4 line inputs, 8 line outputs, an integrated phone add, and a 10-watt power amplifier.

The EF2241, like the Vortex, offers full-bandwidth performance, the fastest acoustic echo cancellation performance available, and our patent-pending third-generation noise cancellation algorithms. Multiple units can be linked or can work in conjunction with Vortex units for large applications requiring telephone call-ins. The Polycom Vortex EF2241 can be programmed from the front panel or by using our Conference Composer software (included).

  • 4 mic / line level inputs (phantom power available for each input)
  • 4 line level inputs
  • 8 line level outputs
  • Individual channel acoustic echo cancellation
  • Third-generation DSP noise cancellation algorithms (patent pending) remove ambient background noise prior to mixing – the result is a much cleaner audio feed
  • 5-band parametric EQ available on all inputs and outputs
  • Speech-driven Neural Network AGC reacts to valid speech patterns only
  • 10-watt power amplifier for driving audio in the room
  • 270 ms tail length, over 10 dB of room gain, and a convergence rate of over 40 dB per second on each mic/line input channel
  • Fully RS232 controllable via AMX, Crestron, or other room controllers
  • No. of mic inputs: 4
  • No. of line inputs: 4
  • No. of line outputs: 8
  • PSTN Interface: Yes
  • Auto mic mixer: Yes
  • Noise cancellation: Yes
  • Auto gain control: Yes
  • EQ on input/output: Yes
  • Echo cancellation: 4 Channels
  • VTX 1000 interface: Yes
  • 10W amplifier: Yes
  • RS232 interface: Yes
  • # of linked devices: 8 Max.
  • Quick install packs: Yes
  • Manufacturer Part Number: 2200-12241-001
